Product Center
Applications ·Motor Drivers ·AC and DC servo drive amplifier ·UPS (Uninterruptible Power Supplies) Features ·Low switching losses ·Low vce(sat) with positive temperature coefficient ·Including fast & soft recovery anti-parallel FWD ·Low inductance case ·High short circuit capability(10us) ·Maximum junction temperature 175℃
Applications ·High frequency drivers ·Solar inverters ·UPS (Uninterruptible Power Supplies) ·Electric welding machine Features ·High speed IGBT in NPT technology ·Low switching losses ·High short circuit capability(10us) ·Including ultra fast & soft recovery anti-parallel FWD ·Low inductance ·Maximum junction temperature 150℃
Features ●VR 75V ●IFAV 150mA Typical Applications ● Extreme fast switches Mechanical Data ● Package: SOD123 ● Terminals: Tin plated leads, solderable per J-STD-002 and JESD22-B102 ● Polarity: Cathode line denotes the cathode end ● Marking: T4
1、BST耐壓超過600V；2、腳位兼容IR2101；3、上下通道輸出延時匹配；4、兼容3.3V、5V、15V 邏輯輸入；5、內置死區時間防止上下通道直通。
1.集成1顆高可靠性HVIC，2顆2.4ohm,2A/500V快恢復MOSFET；2.DIP8小體積，低成本封裝；3. >10us 短路電流耐固能力；4. 集成保護特性： - Shoot-through保護 - VCC&BST-SW UVLO保護檢測 - 過溫度保護。
